The only exception to this fact, in the aviation case, occurs where an airport zoning regulation, made pursuant to the Aeronautics Act, is in force. The Minister of Transport may exercise authority only over lands that are included in an Airport Zoning Regulation made pursuant to the Act.
An Airport Zoning Regulation contains restrictive clauses that describe the activities and uses that are restricted or prohibited and contains a legal description of the lands to which it applies. Individual zoning regulations are included in a listing of regulations made pursuant to the Aeronautics Act and may be found at the following internet address: Aeronautics Act R.
This publication describes not only the operational characteristics of aerodromes but also different types of land uses outside the aerodrome property boundary and recommends, where applicable, guidelines for those land uses in the vicinity of aerodromes. In addition, the source documents have been linked to further explain the technical aeronautical requirements. Aerodrome : Any area of land, water including the frozen surface thereof or other supporting surface used or designed, prepared, equipped or set apart for use either in whole or in part for the arrival, departure, movement or servicing of aircraft and includes any buildings, installations and equipment situated thereon or associated therewith.
Aerodrome Reference Point : The designated point or points on an aerodrome normally located near the geometric centre of the runway complex that:. Graded Area : An area surrounding the runway which is graded to a specified standard to minimize hazards to aircraft which may accidentally run off the runway surface. Heliport : An aerodrome or a defined area on a structure intended to be used wholly or in part for the arrival, departure and surface movement of helicopters.
Obstacle Limitation Surface : A surface that establishes the limit to which objects may project into the airspace associated with an aerodrome consisting of the following; a takeoff surface, an approach surface, a transitional surface and an outer surface. Runway Strip : A defined area including the runway, and stopway if provided, intended to reduce the risk of damage to aircraft running off a runway and to protect aircraft flying over it during takeoff or landing operations.
Water Aerodrome : means an aerodrome that uses an area of water, excluding the frozen surface of that area, for the arrival, departure, movement or servicing of aircraft. This publication is designed to assist planners and legislators at all levels of government in becoming familiar with issues related to land use in the vicinity of aerodromes.
The land use around aerodromes can have significant impacts on safety at the aerodrome and can negatively impact the operational viability of the aerodrome to the detriment of the local community that depends upon it. The compatible land use planning concept is an outgrowth of the focus of attention on the environmental relationship between aerodromes and their community neighbours.
This planning concept is relatively simple and the results can be impressive, but the implementation requires careful study and co-ordinated planning. However, there are still instances where the use of these guidelines will result in more compatible aerodrome and community development.
As new and non-traditional uses of land become more prevalent e. The ninth edition of TP has been revised to address these issues. Where units of measure are quoted in this document, the metric numbers are to be heeded as the equivalent imperial units are approximations only. For the purposes of this document, where the word aerodrome is used, it includes certified aerodromes, non-certified aerodromes, heliports and water aerodromes; where the word airport is used, it specifically means certified aerodromes.
Enquiries relating to the application of these guidelines should be directed to the appropriate Regional Director Civil Aviation. This part will give the reader some insight into those aerodrome operational factors which can affect land uses outside the aerodrome property boundary. Each factor is considered separately and in enough detail to allow general planning conclusions to be drawn.
It is important that any particular land use under consideration be judged from the point of view of all relevant factors. Obstacle Limitation Surfaces are established to ensure the required level of safety. These surfaces normally extend beyond the boundary of the aerodrome and therefore benefit from protection by the enactment of an Airport Zoning Regulation which will prohibit the erection of structures which would violate any of the defined plane surfaces. Where enacted, zoning regulations apply to all the lands, including public road allowances, adjacent to or in the vicinity of an airport; the specific lands are described in the Schedule of the relevant airport zoning regulation.
Lands within an airport boundary are therefore not included in an airport zoning regulation; however, all structures within an airport boundary must comply with obstacle limitation surface requirements, as stated in TP E Aerodrome Standards and Recommended Practices.
For those airports at which an Airport Zoning Regulation has been enacted under the Aeronautics Act, details of the registered zoning plans are available from the Land Registry Office for the district within which the airport is located. Therefore, it is critical that planning and coordination of the siting of obstacles should be conducted in conjunction with an aerodrome operator at the earliest possible opportunity. There are three types of surfaces in place at an aerodrome that should be protected to avoid penetration by objects or structures.
Protection of these surfaces is done by limiting the height of structures, including appurtenances or objects on the ground, to heights that are less than that of the slope surface thereby avoiding penetration of that surface.
Airports that have an Airport Zoning Regulation have these surfaces protected by law and these zoning regulations apply to land that is located outside the property boundary of the airport. Where the facility is an airport, objects penetrating any of these surfaces may affect the operations of the airport and the certification status of the airport.
Where the facility is a non-certified aerodrome, penetration of these surfaces may affect the operations at the aerodrome. Where the facility is a non-certified aerodrome, the standards in TP E Aerodrome Standards and Recommended Practices can be used but are not enforceable; however, the operational integrity of the non-certified aerodrome is enhanced if the designation of the use of land adjacent to the facility is done in line with technical portions of the standards.
A complete description of the standards related to these surfaces may be accessed at the following website:. The following figure will assist the reader in developing a visual picture of the surfaces discussed above. Figure 1: Obstacle Limitation Surfaces. An outer surface shall be established where required for the protection of aircraft conducting a circling procedure or manoeuvring in the vicinity of an aerodrome.
The outer surface establishes the height above which it may be necessary to rake one or more of the following actions:. Note : When the outer surface elevation cannot be held to 45 m, a semi-circular outer surface may be established permitting a circling procedure on one side of the runway. If this compromise solution is not possible, circling as part of an instrument approach procedure should not be recognized, thus eliminating the need for an outer surface.
The outer surface measured from the designated aerodrome reference point or points, shall extend to a horizontal distance of at least:. They are established for each runway direction intended to be used for the take-off and landing of aircraft.
I Runways, 2. If local terrain precludes the use of a glide path, then the lowest usable glide slope should be selected. Figure 3: Obstacle Limitation Surfaces. Transitional surface is a complex surface along the sides of the runway strip and pan of the approach surface that slopes up to the outer surface. Its purpose is to ensure the safety of aircraft at low altitudes displaced from the runway centre line in the approach or missed approach phase. The slope of a transitional surface measured in the vertical, perpendicular to the runway shall be:.
Where topographical or natural obstructions make it economically unreasonable and in the opinion of the Certifying Authority, an equivalent level of safety will be achieved, the transitional surfaces for runways where the code number is 1 or 2, used in Visual Meteorological Conditions VMC may be steepened or eliminated provided the strip width is widened in accordance with the following:. Note : This is intended to provide relief for small aerodromes in mountainous regions, used in VMC, where river valleys, etc.
At other locations an aeronautical study and Headquarters' approval is required before applying the above criteria. The guidance contained in this part is aimed at protecting navigational aids, radars and telecommunications systems which include systems for civil, military, and environmental applications.
Local land use planners and those wishing to erect structures are encouraged to contact regional Transport Canada Civil Aviation offices for assistance in locating any nearby aerodromes and NavCanada for assistance in locating any potentially impacted radars, navigation aids or telecommunications facilities.
Local planners and those wishing to erect structures are encouraged to consult with identified airport and aerodrome operators and NavCanada. NavCanada can be contacted at or by email at landuse navcanada.
The information contained in this part represents the criteria normally applicable for the protection of navigational aids, radars and telecommunications systems. More specific guidance on structures conforming to these values should be available from the owner of the radar, navigational aid or telecommunications system.
Planners should also be aware that, where airport zoning regulations are in effect, specific structures which contravene the values contained within said zoning regulations may sometimes be acceptable, provided that the applicant demonstrates by a technical analysis that such approvals will not cause harmful interference.
Consultation with the radar, navigational aid or telecommunication system owner should take place at an early stage in the project in order to avoid costly redesign or undue pressure when seeking building and site approvals. It is recommended that consultation take place at the building concept stage, before site approval is sought.
The radar, navigational aid or telecommunication system owner should ensure that full coordination takes place with aerodrome and local authorities where there is any air navigation system change that may impact local communities. Note : The development and promulgation of the requirements for the protection of radar, navigational aid or telecommunication systems are the responsibility of the facility owner.
The radar coverage volume for all types of radar systems can be reduced by a structure blocking the transmit or receive signal path. The severity of this blockage is proportional to the size of the structure and varies according to its location.
The size and construction material of buildings and other structures can be controlled to ensure that the radar coverage volume is maintained and that the number of false targets detected is not increased. They are created by transmitted or received signals being reflected from structures. The magnitude of the reflection is proportional to the size of the structure and the electrical behaviour of the material used. Non-metallic materials can reduce the magnitude of the reflection. The protection criteria presented in this section are provided for general guidance purposes only.
No structures exceeding the height of the radar antenna should be built within a radius of m of weather radars. Environment Canada is the entity responsible for siting weather radars in Canada.
The owner or proponent of the structure is responsible for any coordination with Environment Canada. Metallic structures may cause reflection of communication signals.
Although several different standardized types of navigational aids are used to support air navigation, they share the common characteristic that the navigation guidance is derived partially as a function of the direction from which the navigation signals are received. Any structure that causes unwanted reflections of guidance signals will cause some of those signals to be received from a different direction, altering the navigation guidance in a potentially hazardous way.
For this reason, it is important to screen and assess any developments in the vicinity of navigational aids. The following types of structures should be assessed prior to construction to determine the potential impact on navigation signals from an NDB:.
In particular, the equipment requires that:. In general, a clear line-of-sight should be maintained between the antenna system and local flying aircraft. For standard VOR facilities, the following constraints should be applied to maintain the required accuracy of navigation signals:. The following types of structures should be assessed prior to construction to determine the potential impact on navigation signals from a DME:.
ILS supports all-weather precision approach and landing operations. To maintain the safety of landing aircraft, it is critical that the accuracy of ILS navigation signals not be compromised by unwanted reflections or interference. These objects may reflect the ILS signals in unwanted directions, distorting the information provided to aircraft. Planners involved in siting and approval of these sources of interference should contact the ILS facility owner.
For planning purposes, all runways should be considered to be equipped with an ILS at each end. Buildings within the ILS building restricted area are often acceptable after a detailed assessment.
In some cases, measures such as appropriate orientation of the building, shape of reflecting surfaces, etc. For these localizers, the applicable restrictions apply in both directions from the antenna array.
Power lines and substations should be designed, constructed and maintained using state of the art techniques to minimize radiated EMN in the ILS frequency bands. In general, the following should be avoided:. In its many civil aviation responsibilities, Transport Canada remains focused sharply on the safety of air travelers.
This focus has led the department to examine numerous potential hazards, including those found on and in areas around Canadian aerodromes.
Working with industry experts, and based on extensive international scientific research, Transport Canada has confirmed that these hazards include many forms of wildlife, from birds and deer which are often struck by aircraft, to smaller prey animals that attract more hazardous species.
